Max. Safe Working Load |
1,800 in lbs of torque. |
Load Type |
Lifting of gymnasium divider curtains |
Curtain Lift Height |
80 revolutions |
Speed |
10 rpm. |
Electrical Characteristics |
115/1/60 (220/1/50 available upon request) |
Motor |
1 HP/0.75 kW. |
Full Load Amperage |
10 Amps. |
Motor Type |
Instant reverse, low maximum current draw design, thermally protected. |
Duty Cycle |
4 minutes on, 20 minutes off |
Gear Reduction |
Proprietary composite self lubricating gearing with no oil bath |
Drive Drum |
Drive drum is hollow bore style to accept a 2–3/8” O.D. line shaft. The torque transmits via (2) ½” diameter pins installed in holes in the line shaft. |
Braking |
Double worm gearing plus passive uni-directional brake. |
Safety Over-Speed Device |
The winch has a unique built-in Posilok over-speed arrest system that creates an audible clicking as a safety check to ensure proper operation. |
Direction of Rotation |
The winch has a definite lifting direction and a definite lower direction which one must be aware when mounting. |
Limit Switches |
Fully adjustable upper and lower limit switches. |
