Max. Safe Working Load |
Designed to lift a vertical weight of 800 lbs / 363 kg. |
Load Type |
Vertical lifting, pulling on a slope or pulling horizontally. |
Rope |
¼” / 6.35 mm 7 x 19 aircraft cable (rope not supplied with winch). |
Rope Travel |
25 ft / 7.62 m on one layer. A second layer, for 45 ft / 13.7 m total, may be wound if required. |
Rope Speed |
11 ft per minute / 3.35 m per minute. |
Electrical Characteristics |
110 V, 60 Hz. |
Motor |
1 HP / 0.75 KW. |
Full Load Amperage |
10 Amps. |
Motor Type |
Instant reverse, low maximum current draw design, thermally protected. |
Duty Cycle |
4 minutes on, 20 minutes off. |
Gear Reduction |
Proprietary composite self lubricating gearing with no oil bath. |
Rope Drum |
Grooved for accurate winding. Supported by large diameter ball bearings, and with positive through the drum type rope anchor. |
Braking |
Double worm gearing plus passive uni-directional brake. |
Pressure Roller |
Constant pressure type with torsion spring mounting. |
Limit Switches |
Heavy duty upper and lower switches, gear driven for high accuracy. |
Frame |
Semi enclosed for safety. Powder coated for corrosion resistance. |
Weight (As Shipped) |
68 lbs / 31 kg. |
