Max. Safe Working Load |
Designed to lift a vertical weight of 400 lbs / 181 kg |
Load Type |
Vertical lifting |
Strap Type |
1-7/8” wide polyester web. Minimum breaking strength of 2000 lbs |
Rope Travel |
Depends on customer’s choice of strap (48” – 112”) |
Gear Reduction |
Self-locking worm drive |
Braking |
Worm gear and thrust braking |
Frame |
Patented interlocking steel frame for high rigidity and precise alignment. Semi-enclosed for safety. Powder coated for corrosion resistance |
Mounting |
Able to mount to 3” or 3.5” uprights |
Crank Handle Position |
Crank input is on the front face of the unit. Crank folds back for safe storage and security against loss |
Weight (As Shipped) |
6 lbs / 2.7 kg |
